The most commonly selected panel type for industrial coldstores operating between +2 degrees and upward.
100mm high-density CFC free PIR foam injected into 0.5mm hot lacquered white food safe laminated steel. U-Value W/M2K = 0.20. Available for panel lengths, spans and heights for up to 7000mm.
When spans exceed the capabilities of 100mm, during the design phase 125mm insulation is selected.
125mm high-density CFC free PIR foam injected into 0.5mm hot lacquered white food safe laminated steel. U-Value W/M2K = 0.17. Available for panel lengths, spans of 7500mm and heights for up to 8000mm.
When freezer cold stores increase in size it is necessary for these rooms to be constructed from 150mm panels to ensure thermal efficiency.
150mm high-density CFC free PIR foam injected into 0.5mm hot lacquered white food safe laminated steel. U-Value W/M2K = 0.13. Available for panel lengths, spans of 8000mm and heights for up to 9000mm.
When lengthy single spans reaching 10000mm are required, and for very large low temperature stores, we design and install these using 200mm panels to ensure thermal efficiency and structural integrity.
